Type Of Weave > Plain Weave :-

Plain Weave

It is the most commonly used weave. Each Warp Wire crosses alternatively above & below each Weft Wire. Warp & Weft Wire of the same diameter. Aluminum & Fiber glass are widely used in doors & windows for insect & mosquito prevention.

Type Of Weave > Profiled Wire

Profiled WireContent & image both Required

Type Of Weave > Plain Weave > Half Round Wire Mesh

Half Round Wire Mesh Mesh woven from Profiled Half Round Wire is manufactured up to the width of 6500mm without joint. Widely used in Paper & Board, Asbestos Industries

Type Of Weave > Plain Weave > Mosquito Net

Mosquito Net Basic use for protection of mosquito insects and it has long life for protection of any insect bite. supplying in aluminum ,s s gi and brass can also supply in different shade of colour.

Type Of Weave > Plain Weave > Rope Wire Mesh

Rope Wire Mesh Mainly used in Architectural purposes manufacture from s s rope wire consist 7wire generally \ one side other side plian wire.

Type Of Weave > Twilled Weave :-

Twilled Weave

TWILL Weave indicates the wrap & weft wires passes alternatively above two or more & below two or more wires depending upon the patterns of Twill Weave. Such weaves allows use of heavier wire diameter in a particular mesh count than used in Plain weave. These weave has a wide application capable of supporting greater loads & finer retention.

Type Of Weave > Twilled Weave > 3 Weave Pattern

3 Weave Pattern In this weave pattern each weft wire pass thro two warp always by up or down .

Type Of Weave > Twilled Weave > 4 Weave Pattern

4 Weave Pattern In this process of weaving pattern of mesh each weft wire pass over three warp wire in alternate up or down widely used in process of filteration

Type Of Weave > Twilled Weave > 5 Weave Pattern

5 Weave Pattern This process of weaving smooth top surface an open lower surface with a great air pre-melacity, strong and stable mesh. This is type of mesh is ideal for filter heavy water project. In this process of weaving 4 weft wire always down or up pass through one wire weft in alternate with each 4 wire in different pattern of weave,

Type Of Weave > Dutch Weave :-

Dutch Weave

DUTCH Weave refers to the use of a different mesh in warp & weft along with different wire diameter in warp & weft forming a fine mesh in one direction and a coarse mesh in the other direction. This weave results in greater strength with very fine openings and is used to aid more particle retention and increase in filter cake formation than other patterns of weave. This weave pattern has a combination of Plain, Twill & Reverse Pattern.

Type Of Weave > Dutch Weave > Plain Weave Pattern

Plain Weave Pattern DUTCH Plain Weave refers to the use of a heavier warp wire diameter with coarse mesh in conjunction with a lighter weft wire diameter with fine mesh. Each Warp Wire crosses alternatively above & below each Weft Wire. This weave results in greater strength with very fine openings and is used to aid particle retention and increase in filter cake formation. This weave pattern has a combination of Plain, Twill & Reverse Pattern. It widely used for filteration in Oil, Chemical, Screening, Air & Space & other industries

Type Of Weave > Dutch Weave > Twilled Weave Pattern

Twilled Weave Pattern Dutch Twilled Weave is produced by a combination of the features of the Twilled Weave & Dutch Weave. Each Wrap & Weft wires passes alternatively above two or more & below two or more wires depending upon the patterns of Twill Weave. Dutch Twilled Weave supports greater loads & more particle retention as it represents the features of both Twill Weave & Dutch Weave. It is applicable where heavy material filtering is required.

Type Of Weave > Dutch Weave > Reverse Dutch Weave

Reverse Dutch Weave Reverse Dutch Weave is manufactured by lighter wire & fine mesh in warp with a heaver wire & coarse mesh in weft. Reverse Dutch Weave provides greater strength with very fine openings and is used as a filtering medium. Reverse Dutch Weave supports greater loads & more particle retention then Dutch Twilled Weave.

Type Of Weave > Dutch Weave > Mud filter cloth

Mud filter cloth Mud filter cloth is manufactured mainly in Plain Dutch Weave. It is mainly used for Lime Mud Filter. It can be supplied at the width of 6500mm without any joints in S.S. 304 / 304L / 316 / 316L

Type Of Weave > Tortoise Shell Wire Mesh :-

Tortoise Shell Wire Mesh

It consists of a hexagonal hole mesh with bar steel pressed and punched. The pitch of the Mesh varies from 20 mm to 60 mm. The strip width varies from 10mm to 25mm & the thickness from 1mm to 2mm. It is widely used especially as one of main component of catalyst equipment. It is improves the wear resistance lining strength.

Type Of Weave > Multiplex Weave :-

Multiplex Weave

Multiplex Weave is also a type of a Twill Weave Pattern. Multiplex Weave is manufactured by interweaving 4, 5 or 6wire in single warp & weft rather than single wire. The number of pores increases due to the special mesh structure.

Type Of Weave > Plastic Mesh :-

Plastic Mesh

Content Required

Type Of Weave > Plastic Mesh > Sun Shade Net

Sun Shade Net It is stitched 3,5,6 per inch are woven HDPE or Monofilament material durable and look stitched, It is widely used in agriculture to protect the direct heat on product and on site. It can be supplied in width from 1.5mtr to 6mtr.

Type Of Weave > Plastic Mesh > Plastic Mesh for Filteration

Plastic Mesh for Filteration It is widely use for filter of juice and also protection from mosquitoes.
