INDUSTRIAL SCREEN (Pre Crimped Wire Mesh)

Pre Crimped Wire Mesh

Wires are Pre – Crimped to attain their desired & specific opening. Patter of Weave depends mainly on the Application. Wire of any diameter & composition can be used.

Industrial Screen - Single Crimped Mesh

Wedge Wire Screen Wire Mesh manufactured where the weft or the warp wire is Pre - Crimped before weaving& the other warp or weft is woven non-crimped. This process provides rigidity to the mesh.

Industrial Screen - Double Crimped Mesh

With Edge Preparation Wire Mesh manufactured where the warp & the weft wires are Pre – Crimped to the desired size before weaving. It restricting their random movement and ensuring an accurate and consistent Square Opening or Rectangular opening.

Industrial Screen - Intermediate Crimped Mesh

Single Crimped Mesh Wire Mesh manufactured where the warp & weft wires are Pre – Crimped & are woven with extra crimp or corrugation between them. It provides the proper locking for the wires, adds rigidity & accuracy where the opening is more with respect to the wire dia.

Industrial Screen - Dovex / Flat Top

Double Crimped Mesh Wire Mesh manufactured where the wrap & weft wires are Pre – Crimped & are locked underneath the wire. This results in one side the mesh is crimped & the other side it has a flatter & smooth surface. It improves the material flow & also acts as a support to other fine mesh on its top.

Industrial Screen - Long Slot Screen

Intermediate Crimped Mesh Wire Mesh manufactured where the warp or weft wires are arranged in a set of 3 or more wires with long gaps in between the set as desired or required forming a long rectangular opening at regular interval. The other side wire is woven one after the other. Such Screen provides maximum open area & prevents blinding or plugging of material in the mesh as compared to square shaped wire mesh. It is also called Fertiliser Screen as it is widely used in the Fertiliser Industry.

Industrial Screen - Harp screen

Dovex / Flat Top This screen manufactured where the warp wires are deeply Pre - Crimped & arranged. The weft wire is then woven single wire or double wire at a time in set of 3 or more & at regular intervals. The wires vibrate independently from one & other preventing material blinding & plugging.

Industrial Screen - Lock Crimped

Long Slot Screen Wire Mesh manufactured where the warp & weft wires are Pre – Crimped&both the wires are given a bend. It provides the proper locking for the wires, adds rigidity & accuracy where the opening is more with respect to the wire dia.

Industrial Screen - With Edge Preparation Panels Details

Harp screen Vibrating screen can be supplied with type of different type of Edge Prepration. Edges of the Screens are folded at different degrees on any of the side (Width / Length) with or without sheet. Metal Fabrication are also supplied in Stainless Steel, Galvanised Sheet, Mild Steel Sheet or Rubber Sheet are used extensively used for Edge Preparation.

Industrial Screen - Wedge Wire Screen

Tyrod Screen Wedge Wire Screens are manufactured in various shapes such as Flat Panels, Curved Sieve Bend, Conical Baskets, Cylinders, Trough Disk in one piece or in segments. Widely use in Sugar, Pharma, Food, Coal, Chemical Plant, Petro and Filteration, Water Treatment etc

Industrial Screen - Mud Screen

Lock Crimped Wire Screen main used for Petrochemicals Industries for Oil extractions.
